Thick housing Industrial caster, steel with zinc plating fork,Blue elastic rubber wheel,Double ball bearing
| Steel housing with bright zinc plating |
| Blue elastic rubber wheel tread, nylon center |
| Double ball bearings |
P161-23F100x36 P161-23F125x36
D161-23F100x36 D161-23F125x36
P161-23F100x36S P161-23F125x36S
G161-23F100x36 G161-23F125x36
G161-23F100x36S G161-23F125x36S
| Item Code | Wheel Diameter (mm) | Wheel Thick (mm) | Weight (kg) | Total Height (mm) | Eccentric Throw (mm) | Plate Hole (mm) | Plate Dimension (mm) | Plate Hole Spacing (mm) | Barrier Width (mm) |
| P161-23F100x36 | 100 | 36 | 200 | 128 | 45 | 9 | 105×82.5×3 | 80×60 | 3.5 |
| P161-23F125x36 | 125 | 36 | 300 | 153 | 45 | 9 | 105×82.5×3 | 80×60 | 3.5 |
| D161-23F100x36 | 100 | 36 | 200 | 128 | / | 9 | 105x92x3 | 80×60 | 3.5 |
| D161-23F125x36 | 125 | 36 | 300 | 153 | / | 9 | 105x92x3 | 80×60 | 3.5 |
| P161-23F100x36S | 100 | 36 | 200 | 128 | 45 | 9 | 105×82.5×3 | 80×60 | 3.5 |
| P161-23F125x36S | 125 | 36 | 300 | 153 | 45 | 9 | 105×82.5×3 | 80×60 | 3.5 |
| Item Code | Wheel Diameter (mm) | Wheel Thick (mm) | Weight (kg) | Total Height (mm) | Eccentric Throw (mm) | Plate Hole (mm) | Plate Dimension (mm) | Plate Hole Spacing (mm) | Barrier Width (mm) |
| G161-23F100x36 | 100 | 36 | 200 | 128 | 45 | 12.2 | 3.5 | ||
| G161-23F125x36 | 125 | 36 | 300 | 153 | 45 | 12.2 | 3.5 | ||
| G161-23F100x36S | 100 | 36 | 200 | 128 | 45 | 12.2 | 3.5 | ||
| G161-23F125x36S | 125 | 36 | 300 | 153 | 45 | 12.2 | 3.5 |
